INA110KP

INA110KP

Specifications

Manufacturer:          Texas Instruments

Product Category:   Instrumentation Amplifiers

RoHS: Details

Series:           INA110

Number of Channels:         1 Channel

3 dB Bandwidth:      2.5 MHz

SR - Slew Rate:       12 V/us

CMRR - Common Mode Rejection Ratio:          106 dB

Ib - Input Bias Current:       50 pA

Vos - Input Offset Voltage: 250 uV

Supply Voltage - Max:        36 V

Supply Voltage - Min:         12 V

Operating Supply Current: 3 mA

Minimum Operating Temperature:           - 55 C

Maximum Operating Temperature:          + 125 C

Mounting Style:        Through Hole

Package/Case:        PDIP-16

Packaging:   Tube

Amplifier Type:         Instrumentation Amplifier

Brand:            Texas Instruments

Dual Supply Voltage:          +/- 15 V

en - Input Voltage Noise Density: 10 nV/sqrt Hz

Gain Error:    0.01 %

Gain V/V:       1 V/V, 10 V/V, 100 V/V, 1000 V/V

Height:           4.57 mm

INL - Integral Nonlinearity: 0.01 %

Length:          19.3 mm

Maximum Input Resistance:         5 TOhms

Operating Supply Voltage: 12 V to 36 V

Output Current per Channel:        25 mA

Product:         Instrumentation Amplifiers

Product Type:           Instrumentation Amplifiers

50

Subcategory:            Amplifier ICs

Voltage Gain dB:     116 dB

Width: 6.35 mm

Unit Weight:  1,054 g
